Intel Core i5-14400F Intel� Core� i5 LGA 1700 Intel i5-14400F 64-bit Intel Core

Intel Core i5-14400F Intel� Core� i5 LGA 1700 Intel i5-14400F 64-bit Intel Core

Intel Core i5-14400F. Processor family: Intel� Core� i5, Processor socket: LGA 1700, Processor manufacturer: Intel. Memory channels: Dual-channel, Maximum internal memory supported by processor: 192 GB, Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM. Market segment: Desktop, Use conditions: PC/Client/Tablet, PCI Express slots version: 4.0, 5.0. Processor package size: 45 x 37.5 mm. L2 cache: 9728 KB, Maximum internal memory: 192 GB

Graphics


On-board graphics card

No


On-board graphics card model

Not available


Discrete graphics card

No


Discrete graphics card model

Not available



Processor special features


Mode-based Execute Control (MBE)

Yes


Enhanced Intel SpeedStep Technology

Yes


Intel� Speed Shift Technology

Yes


Intel� Gaussian & Neural Accelerator (Intel� GNA) 3?0

Yes


Intel� Hyper Threading Technology (Intel� HT Technology)

Yes


Intel� Turbo Boost Technology

2.0


Intel� Control-flow Enforcement Technology (CET)

Yes


Intel� Volume Management Device (VMD)

Yes


Intel� Standard Manageability (ISM)

Yes


Intel� Thread Director

Yes


Intel� Boot Guard

Yes


Intel Virtualization Technology for Directed I/O (VT-d)

Yes


Intel� OS Guard

Yes


Intel Virtualization Technology (VT-x)

Yes


Intel� Secure Key

Yes


Intel� AES New Instructions (Intel� AES-NI)

Yes


Intel� Deep Learning Boost (Intel� DL Boost)

Yes


Intel VT-x with Extended Page Tables (EPT)

Yes


Intel 64

Yes



Processor


Processor base power

65 W


Processor operating modes

64-bit


Performance cores

6


Performance-core base frequency

2.5 GHz


Maximum turbo power

148 W


Processor family

Intel� Core� i5


Processor socket

LGA 1700


Processor boost frequency

4.7 GHz


Processor ARK ID

236777


Efficient-core base frequency

1.8 GHz


Processor generation

Intel Core i5-14xxx


Processor threads

16


Processor codename

Raptor Lake


Processor cache

20 MB


Memory bandwidth supported by processor (max)

76.8 GB/s


Box

Yes


Efficient-core boost frequency

3.5 GHz


Efficient cores

4


Processor cache type

Smart Cache


Maximum number of DMI lanes

8


Performance-core boost frequency

4.7 GHz


Cooler included

Yes


Processor model

i5-14400F


Processor manufacturer

Intel


Processor cores

10



Weight & dimensions


Processor package size

45 x 37.5 mm



Logistics data


Harmonized System (HS) code

8542310001



Memory


Memory types supported by processor

DDR4-SDRAM, DDR5-SDRAM


Memory bandwidth (max)

76.8 GB/s


Maximum internal memory supported by processor

192 GB


Memory channels

Dual-channel



Technical details


Status

Launched


Launch date

Q1'24



Other features


L2 cache

9728 KB


Maximum internal memory

192 GB



Features


Use conditions

PC/Client/Tablet


Direct Media Interface (DMI) Revision

4.0


Scalability

1S


Commodity Classification Automated Tracking System (CCATS)

740.17B1


Embedded options available

No


Execute Disable Bit

Yes


Export Control Classification Number (ECCN)

5A992C


Thermal Monitoring Technologies

Yes


PCI Express slots version

4.0, 5.0


Idle States

Yes


Supported instruction sets

AVX 2.0, SSE4.1, SSE4.2


Maximum number of PCI Express lanes

20


Market segment

Desktop


PCI Express configurations

1x16+1x4, 2x8+1x4


CPU configuration (max)

1



Operational conditions


Tjunction

100 �C
