Fanuc A03B-0807-C159 A0A12F Output Module (Missing Cover)

Condition: Used
Dimensions: 12.00 x 9.00 x 6.00 inches (L x W x H)
Weight: 0.12 Lbs.

12-point digital output module used in Fanuc PLC systems for controlling field actuators such as relays, solenoids, and indicator lamps. Offers reliable switching performance and channel diagnostics for factory automation applications. Technical Specifications: Model Number: A03B-0807-C159 Module Type: AOA12F Output Unit Output Channels: 12-point digital outputs Output Type: Relay (Form A – normally open contacts) Rated Load Voltage: 24 VDC or 120/240 VAC Rated Load Current: 2 A per point (resistive load) Total Output Current: Max 8 A (per module) Contact Type: Mechanical relay Response Time: Typically 10 ms (ON/OFF) Insulation: Relay contact isolation from logic circuit Status Indicators: LED per channel for output ON/OFF indication Connector Type: 20-pin terminal block Mounting: Fanuc-compatible I/O rack (backplane system) Power Source: Supplied from rack backplane Operating Temperature: 0°C to 60°C Humidity Range: 5% to 95% RH (non-condensing) Weight: Approx. 250 g Manufacturer: FANUC Corporation Made in: Japan Please review pictures carefully and let us know if you have any questions!
